Adira GH Series – Shear

Do you need a cut tailored to suit your requirements? Then the GH shear is the solution for you!

The GH, a swing cutting machine, allows you to adapt each cut to your specific needs through a careful selection of options. Please call about our long list of options that will allow you to reach full automation of the operation, including palletizing.

Call the Ocean Machinery sales team TODAY at (954) 956-3131 or Toll Free 1 (800) 286-3624 or fill out our online info request form for more information on ADIRA products.

Category:

Adira GH Series - Shear

FEATURES +
  • Multiple thicknesses and sizes
  • Swing cut
  • Samll fixed angle to suit all thicknesses
  • Capacity for mild and stainless steel
  • Patented “SCSC” – Combined Sheet Support System
  • Sturdy, reliable
  • Energy efficient
SPECS+
GH Series GH 00420 GH 00630 GH 00640 GH 00660 GH 01030 GH 01040 GH 01330 GH 01340 GH 01360
Cutting Capacity – Mild Steel (45daN/mm2): mm 4 6.5 6.5 6.5 10 10 13 13 13
Cutting Capacity – Stainless Steel (70daN/mm2): mm 2.5 4 4 4 6.5 6.5 8 8 8
Cutting Length: mm 2050 3050 4050 6100 3050 4050 3050 4050 6120
Frame Gap: mm 260 260 260 260 260 260 260 260 260
Rake Angle: deg. 11/6 11/3 11/3 11/6 2 11/2 2 11/2 12/5
Blade Clearance Adjustment: mm 0.05-0.6 0.05-1.1 0.05-1.1 0.05-1.2 0.05-1.6 0.05-1.6 0.05-2 0.05-2 0.05-2
Motor Power: Kw 9 15 15 18 15 15 18 18 18
Number of Holddowns: 9 13 19 25 16 22 16 22 31
Back Gauge Range: mm 1000 1000 1000 1000 1000 1000 1000 1000 1000
Stroke per Minute: 45 24 21 19 10 11 9 8 6
Length: mm 2950 3950 4980 7120 3980 4980 3980 4980 7100
Width: mm 2480 2480 2480 2580 2820 2820 2480 2820 3100
Width for Transport: mm 2180 2180 2180 2280 2280 2280 2280 2280 2450
Height: mm 1730 1730 1825 2150 2150 2150 2150 2150 2400
Approx. Weight: Kg 5000 5900 8100 15000 10000 13500 10000 13500 31000
MEDIA+

Please call for more information about ADIRA GH Series Shear 1 (800) 286-3624

OPTIONS +

Please call for more information about ADIRA GH Series Shear 1 (800) 286-3624

Description

Do you need a cut tailored to suit your requirements? Then the GH shear is the solution for you!

The GH, a swing cutting machine, allows you to adapt each cut to your specific needs through a careful selection of options. Please call about our long list of options that will allow you to reach full automation of the operation, including palletizing.

Call the Ocean Machinery sales team TODAY at (954) 956-3131 or Toll Free 1 (800) 286-3624 or fill out our online info request form for more information on ADIRA products.
