OCEAN STRUCTURAL SOLUTIONS

    • Provides exceptional accuracy of hole placement.
    • Very space efficient.
    • Simple and easy to operate.
    • No computer experience required.
    • Fully automatic measuring, layout and drilling cycle.
    • Fastest return on investment of all Ocean products.
    Learn More

    Avenger

    CNC Beam Drill Line

    • Drills, Mills – Marks – Scribes – Threads – Counter-sinks - Counter-bores, and More!
    • Processes profiles up to 48” in height.
    • 8 position tool changer.
    • Automatic marking of all welded attachments.
    • Spindle moves 5” on X axis and 48” on Y axis w/part clamped.
    Learn More

    AVENGER PLUS

    CNC MULTI-FUNTION DRILL LINE

    • Simple and easy to operate.
    • Eliminates manual layout & punching of angles and flat bar.
    • Processes angle up to 6 x 6 x 5/8” and flat bar up to 6 x 5/8“.
    • Easily processes short clip angles and long bracing angles.
    • Fully automatic punching and shearing cycle.
    • Very space efficient – more compact than other angle lines.
    Learn More

    CLIPPER II

    CNC ANGLE LINE

    • Automated welding of attatchments for structural steel.
    • Beams and columns up to 40” high.
    • Ideal for angles, stiffeners, gussets, fin plates, end plates
      and other standard parts.
    • Minimal maintenance required.
    • Compatible with Tekla & SDS2.
    Learn More

    CHALLENGER

    ROBOTIC WELDER

    • Simple and easy to operate.
    • 5-axis fully articulated cutting torch.
    • Copes and cuts beams, channel, angle, plate, tube.
    • Cuts steel at speeds of up to 30 inches per minute depending on material thickness and hardness.
    • Automatic or manual in-feed and out-feed conveyors.
    Learn More

    Liberator

    CNC Beam coper

    • Small footprint: 12 ft x 25ft of floor space and 13 ft headroom.
    • Handles a wide variety of shapes up to 40 inches high.
    • Produces surfaces up to White Metal Blasting SSPC SP5.
    • Completely integrated, requiring only in & outfeed conveyors.
    • Speed is easily adjusted to achieve the desired surface finish.
    • Full installation and training provided with purchase.
    Learn More

    Blaster

    Shot Blasting System

    • Dual column – Dual miter.
    • Efficient cutting of all profiles and materials.
    • Laser guide for precise positioning.
    • Easy adjustment of feed rate and cutting system.
    • Hydraulic blade brush keeps the blade gullets clean.
    • Console can be positioned for operator viewing and safety.
    Learn More

    Terminator

    Band Saw

    • Ensures easy profile alignment to drill line datum blocks.
    • Ideal for welding operation where profiles need rotating
    • Eliminates the need to tie up overhead cranes or forklifts.
    • Eliminates labor assistance in material handling.
    • Minimizes operator fatigue from heavy lifting.
    • Maximizes operator safety.
    Learn More

    Flipper

    Beam Rotator

    • 3 component modular system. – Powered roller conveyors are available in 4′ and 9′ lengths.
      – Cross transfers are available in standard 20′ or 40′ lengths.
      – Remote Controlled Measuring system features a stop that
      is attached to the out-feed conveyor.
    Learn More

    Eliminator

    Material Handling

HOW TO

Ocean News

  • Australian fabricator creates magic with the Avenger PLUS

    Jarrod Slatter, the project manager at Coasteel Engineering in Australia, showed us all just how much power there is contained within the latest Ocean Avenger PLUS multifunction machine.[...]

    Read More
  • Challenger Robotic Welder Webinar

    Ocean Machinery and their manufacturing partner AGT Robotics recently performed a LIVE webinar for a large contingent of structural steel and metal building fabricators. Here is the recording[...]

    Read More
  • avenger-plus-cnc-beam-drill-line

    Scribing layout of welded attachments with Avenger PLUS

    So many of us purchase feature loaded devices, and then use only a fraction of the features. Just think of how much functionality goes wasted in our fancy[...]

    Read More
